Submersible Mixer - KDS PUMPS

Submersible Mixer - KDS PUMPS

Submersible Mixers are ideal for agitating, blending, mixing, dissolving, and suspension of solids in municipal treatment plants, industry, and agriculture.

RANGE

Temperature : up to 95 deg° C

Viscosity : up to 20 cst

Sp. Gr. : 1.15

Solids content : up to 10% by wt

Power Supply : 415V, 50 Hz, 3 phase

APPLICATION

-Equalisation/collection tanks

-Neutralisation pits

-Sludge mixing in STPs

-Pre-digestion mixing

-Anaerobic digesters

-Nitrification and De-Nitrifications tanks

-Chemical Mixing Tank (Lime/Poly)

FEATURES

-Compact, hydraulically optimized design

-Self-cleaning

-The motor is monitored by temperature sensors and a moisture sensor

-Triple dynamic sealing system consisting of two mechanical seals (SIC/SIC) and a lip seal

-An absolutely water-tight, resin-embedded cable entry protects

-An absolutely water-tight, resin-embedded cable entry protects the motor against moisture

-Reduced energy costs

-Shorter mixing times

-Minimal risk of motor overloading

-Easy installation

-Small space requirements

MATERIAL OF CONSTRUCTION

- CI / SS304 / SS316 / SS316L
