Teflon Lined Pump - KDS PUMPS

Teflon Lined Pumps are manufactured using qualitative components and thus, are introduced with the assurance of offering flawless performance in chemical processing. Prices offered are minimal and these products are delivered in a convenient procedure.

RANGE

Capacity : Up to 250 M3/hr

Head : Up to 90 metres

Discharge Size : 25 mm to 100 mm

Temperature : Max. 200°C

Pressure : Up to 9 Kg/cm2

Speed : up to 3500 rp

APPLICATION

-Water treatment plant, ETP, electro plating, picking & steel rolling mill, Oil industries.

-Excellent for transfer and loading – unloading like HCL, Sulphuric Acid/Alkali, and Caustic Liquid.

-Scrubbing of corrosive gases like NH3, CO2, SO3, SO2, SO2, I2, F2, Br2, Cl2, etc…

-For handling liquids in various industries like textile, paper, cellulose, sugar, steel, food, having temperature range, materials, etc…

-Ideal for circulation of chemical in metal finishing industry.

-Natural choice for pickling line & scrubber in steel plants.

-High capacity transfer pump, filter press for dyes & chemicals, descaling oil & other fuels.

-Pesticide / Insecticide Plants, Chlorine Plants.

-Pharmaceutical bulk Drug Plants, Heavy duty chemical plants..

FEATURES

-All wetted parts are solid injection moulded PFA/FEP, extra wall thickness to combat severe corrosive condition.

-Replaceable PFA/FEP casing liner-reduces the maintenance cost.

-Resistance to most chemicals and solvents.

-High thermal stability – continuous duty up to 120ºC temperature.

-Mechanical strength at elevated temperature.

-High abrasion resistance.

-Resistance to sunlight and nuclear radiation, fungus.-

-Low flame and smoke characteristics.

-Low permeability to most gases and liquids.

-Cold weather impact strength.

-Low maintenance cost.

-Can be supplied bare-shaft or with IE3 motors for energy saving.

MATERIAL OF CONSTRUCTION

- PFA/FEP
